Observation Head：Gemel Binocular Head, 30°inclined, Interpupillary



                 Distance 48mm-75mm；



Eyepiece：WF10X/22mm；



Nosepiece：Backward Quadruple Nosepiece；



Objective：High Contrast Infinity Plan objectives 4X, 10X, 40X(S), 100X(S, OIL)；



Condenser：N.A=1.25 Abbe Condenser with iris diaphragm & filter；



Focusing：Coaxial Coarse & Fine Focusing knob. Fine Focusing scale value 0.001mm.



                  Coarse Focusing Travel 37.7mm/circle. Fine Focusing Travel 0.1mm/circle,



                Focusing Range 24mm.



1. Mechanical Stage：Double Layer Mechanical Stage. Graphite-Processed Surface.
2.
3.                Stage Size, 216mm*150mm. Moving Range, 75mm*55mm.
4.
5. Illumination：Kohler Illumination System. 3W LED Illumination. Brightness Adjustable；
